D-Link DES-108 8-port 10/100 Metal Housing Desktop Switch

Podrobný popis

D-Link DES-108 8-port Fast Ethernet Switch

OVERVIEW

D-Link’s DES-108 Fast Ethernet switch provides a cost-effective way for SOHO and SMB to create a small network and connect computers, wireless Access Points, IP cameras, network printers and other Ethernet devices quickly and easily without complicated configurations. This switch comes with 8 Fast Ethernet ports with an auto-sensing function to detect the maximum speed of the connected devices, allowing you to run your network with the best possible performance. Its fanless design makes the DES-108 completely silent so it is ideal for offices, libraries or meeting rooms.

FEATURES

• Plug and Play operation

• 8 Fast Ethernet ports

• Non-blocking architecture: simultaneous full speed on all ports

• Fanless, silent operation to fit in any environment

• Quality of Service (QoS) queues for traffic prioritisation

• Solidly built with metal housing

• D-Link Green™ technology, saves energy and increases the product’s lifespan

SPECIFICATIONS

Standards

• IEEE 802.3 10BASE-T Ethernet

• IEEE 802.3u 100BASE-TX Fast Ethernet

• ANSI/IEEE 802.3 NWay auto-negotiation

• IEEE 802.3x flow control

• IEEE 802.3az Energy Efficient Ethernet (EEE)

Layer2 Features

• MAC address table: 1K

• Auto MDI/MDIX crossover for all ports

• Store-and-forward switching scheme

• Full/half-duplex for Ethernet/Fast Ethernet speeds

• Jumbo Frames: 1536 Bytes

Switching fabric

• 1.6 Gbps

Data Transfer Rates

• Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)

• Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)

Packet Filtering/Forwarding Rates

• Ethernet: 14,880 pps per port

• Fast Ethernet: 148,800 pps per port

RAM Buffer

• 768 KB

LED Indicators

• Per port: Link/Activity

• Per device: Power

Quality of Service (QoS)

• Supports 802.1p QoS

• 2 Queues, WRR Mode

Green features

• Energy Efficient Ethernet (EEE) standard

• RoHS compliant

Power

• External 5 V/1 A Level “V” Power Adapter

Power Consumption (DC input)

• Standby: 0.63 watts

• Maximum 2.1 watts

MTBF

• 511,323 hours

Temperature

• Operating: 0 to 50 °C

• Storage: -10 to 70 °C

Humidity

• Operating: 10% to 90% RH non-condensing

• Storage: 5% to 90% RH non-condensing

Dimensions (W x D x H)

• 162 x 102 x 28 mm

Certifications

• FCC Class B

• ICES-003 Class B

• CE Class B

• C-Tick Class B

• VCCI Class B

• cUL

• CB
